BCO - 6882 - Lazy Susan Half-Moon 2 Shelf (Pivot and Slide) Blind Corner Accessories

BCO – 6882 – Lazy Susan Half-Moon 2 Shelf (Pivot and Slide) Blind Corner Accessories

Category: SKU: BCO - 6882

Description

Every blind corner base cabinet can become functional with Rev-A-Shelf?s
Half Moon Shelf System. The Half Moon Series includes standard and
90-degree hinge euro brackets and chrome-plated shaft and mounting
brackets to help distribute the weight from the cabinet wall to the
floor of the cabinet. In addition, the color coated shelf supports match
the shelf and provide maximum deflection support.

    6882-31-15-570

    • (2) Almond Shelves and pivot and slide hardware
    • 13 1/4″ minimum required opening
    • 2-Shelf 31″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Limited lifetime warranty

    6882-31-11-570

    • (2) White Shelves and pivot and slide hardware
    • 13 1/4″ minimum required opening
    • 2-Shelf 31″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Limited lifetime warranty

    6882-33-15-570

    • (2) Almond Shelves and pivot and slide hardware
    • 16-1/8″ minimum required opening
    • 2-Shelf 33″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Image shown is of 31″ model. Actual unit is 33″.
    • Limited lifetime warranty

    6882-33-11-570

    • (2) White Shelves and pivot and slide hardware
    • 16-1/8″ minimum required opening
    • 2-Shelf 33″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Image shown is of 31″ model. Actual unit is 33″.
    • Limited lifetime warranty

    6882-39-15-570

    • (2) Almond Shelves and pivot and slide hardware
    • 19 1/4″ minimum required opening
    • 2-Shelf 39″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Image shown is of 31″ model. Actual unit is 39″.
    • Limited lifetime warranty

    6882-39-11-570

    • (2) White Shelves and pivot and slide hardware
    • 19-1/4″ minimum required opening
    • 2-Shelf 39″ Polymer Half Moon Susans
    • Designed for a blind corner cabinet application
    • Image shown is of 31″ model. Actual unit is 39″.
    • Limited lifetime warranty

Physical Specifications

Part # Width
(min to max) Depth
(min to max) Height
(min to max) Weight Color : Finish 6882-31-15-570 31″ 15-1/2″ 15-7/8″ 23 lbs. Almond : Polymer 6882-31-11-570 31″ 15-1/2″ 15-7/8″ 23 lbs. White : Polymer 6882-33-15-570 33″ 16-1/2″ 15-7/8″ 26.45 lbs. Almond : Polymer 6882-33-11-570 33″ 16-1/2″ 15-7/8″ 26 lbs. White : Polymer 6882-39-15-570 39″ 19-1/2″ 15-7/8″ 34 lbs. Almond : Polymer 6882-39-11-570 39″ 19-1/2″ 15-7/8″ 34 lbs. White : Polymer

Minimum Cabinet Opening Face Frame Part # Width Depth Height 6882-31-15-570 13-1/4″ “ “ 6882-31-11-570 13-1/4″ “ “ 6882-33-15-570 16-1/8″ “ “ 6882-33-11-570 16-1/8″ “ “ 6882-39-15-570 19-1/4″ “ “ 6882-39-11-570 19-1/4″ “

“

Additional information

Weight 15 kg
